springboot mybatisplus shiro jwt redis JAVA从零搭框架

home 编辑时间 2019/04/24

![](/api/file/getImage?fileId=5d527c6016199b2a52000b0c)

## 前言
需求是自己搭一套空的后台项目API框架，并完成基本的配置，和基本的数据库表以及自动生成系统，为方便以后开发项目可以快速启动。

### 基本
springboot 2.1.4
mybatisplus 3.4.0

### 权限控制
shiro 1.4.0
jwt 3.8.0

### 调试
swagger2 2.7.0

### 数据库
mysql 5.7
redis 4.0.9

## 正文

1 新建一个springboot项目
截图省略
<br>
<br>
2 maven依赖 pom.xml
```xml
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.1.4.RELEASE</version>
        <relativePath/>
    </parent>
    <groupId>com.service</groupId>
    <artifactId>test</artifactId>
    <version>1.0.0</version>
    <name>test</name>
    <description>test service</description>


    <properties>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
        <java.version>1.8</java.version>
        <mysql.version>5.1.38</mysql.version>
        <commons.lang.version>2.6</commons.lang.version>
        <fastjson.version>1.2.45</fastjson.version>
        <jedis.version>2.9.0</jedis.version>
        <mybatisplus.spring.boot.version>3.1.0</mybatisplus.spring.boot.version>
        <mybatisplus.generator.version>3.1.0</mybatisplus.generator.version>
        <freemarker.version>2.3.28</freemarker.version>
        <swagger.version>2.7.0</swagger.version>
        <commons.lang.version>2.6</commons.lang.version>
        <jwt.version>3.8.0</jwt.version>
        <apache.shiro.version>1.4.0</apache.shiro.version>
    </properties>

<dependencies>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>

        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
            <version>${mysql.version}</version>
        </dependency>
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>${mybatisplus.spring.boot.version}</version>
        </dependency>
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-generator</artifactId>
            <version>${mybatisplus.generator.version}</version>
        </dependency>
        <dependency>
            <groupId>org.freemarker</groupId>
            <artifactId>freemarker</artifactId>
            <version>${freemarker.version}</version>
        </dependency>

        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger2</artifactId>
            <version>${swagger.version}</version>
        </dependency>
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger-ui</artifactId>
            <version>${swagger.version}</version>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-data-redis</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-configuration-processor</artifactId>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>redis.clients</groupId>
            <artifactId>jedis</artifactId>
            <version>${jedis.version}</version>
        </dependency>

        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>${fastjson.version}</version>
        </dependency>

        <dependency>
            <groupId>commons-lang</groupId>
            <artifactId>commons-lang</artifactId>
            <version>${commons.lang.version}</version>
        </dependency>

        <dependency>
            <groupId>org.apache.shiro</groupId>
            <artifactId>shiro-spring</artifactId>
            <version>${apache.shiro.version}</version>
        </dependency>
        <dependency>
            <groupId>com.auth0</groupId>
            <artifactId>java-jwt</artifactId>
            <version>${jwt.version}</version>
        </dependency>
    </dependencies>

<build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>

            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-surefire-plugin</artifactId>
                <configuration>
                    <skipTests>true</skipTests>
                </configuration>
            </plugin>

</plugins>
    </build>

<repositories>
        <repository>
            <id>public</id>
            <name>aliyun nexus</name>
            <url>http://maven.aliyun.com/nexus/content/groups/public/</url>
            <releases>
                <enabled>true</enabled>
            </releases>
        </repository>
    </repositories>
    <pluginRepositories>
        <pluginRepository>
            <id>public</id>
            <name>aliyun nexus</name>
            <url>http://maven.aliyun.com/nexus/content/groups/public/</url>
            <releases>
                <enabled>true</enabled>
            </releases>
            <snapshots>
                <enabled>false</enabled>
            </snapshots>
        </pluginRepository>
    </pluginRepositories>
</project>

```
<br>
3 接下来是新建一个`config` 文件夹开始配置
Swagger2只需要一个`SwaggerConfig.java` 就可以配置完成
项目启动后swagger的访问路径是
http://localhost:port/context-path/swagger-ui.html
(端口号、项目路径根据实际情况替换)

`SwaggerConfig.java`
```java
package com.kpiservice.kpi.config;

import io.swagger.annotations.ApiOperation;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import springfox.documentation.builders.ApiInfoBuilder;
import springfox.documentation.builders.PathSelectors;
import springfox.documentation.builders.RequestHandlerSelectors;
import springfox.documentation.service.ApiInfo;
import springfox.documentation.service.ApiKey;
import springfox.documentation.spi.DocumentationType;
import springfox.documentation.spring.web.plugins.Docket;
import springfox.documentation.swagger2.annotations.EnableSwagger2;

import java.util.List;

import static com.google.common.collect.Lists.newArrayList;

@Configuration
@EnableSwagger2
public class SwaggerConfig {
    @Bean
    public Docket createRestApi() {
        return new Docket(DocumentationType.SWAGGER_2)
            .apiInfo(apiInfo())
            .select()
            //加了ApiOperation注解的类，才生成接口文档
            .apis(RequestHandlerSelectors.withMethodAnnotation(ApiOperation.class))
            //包下的类，才生成接口文档
            //.apis(RequestHandlerSelectors.basePackage("com.gemini.controller"))
            .paths(PathSelectors.any())
            .build()
            .securitySchemes(security());
    }

private ApiInfo apiInfo() {
        return new ApiInfoBuilder()
            .title("API接口调试页面")
            .description("api接口")
//            .termsOfServiceUrl("http://www.xxx.com")
            .version("1.0.0")
            .build();
    }

private List<ApiKey> security() {
        return newArrayList(
            new ApiKey("token", "token", "header")
        );
    }

}
```

# 未完待续

## END
